标称电压

51.2V

Nominal voltage

标称容量

50Ah/2560Wh

100Ah/5120Wh

200Ah/10240Wh

230Ah/11776Wh

Nominal capacity

电芯类型

磷酸铁锂 (LiFePO₄)

Cell type

组合方式

16S1P

16S1P

16S1P

16S1P

Composition

充电截止电压

58.4V

Charging cutoff  voltage

放电截止电压

40V

Discharge Cut-off Voltage

最大持续放电电流

50A

100A

200A

200A

Maximum continuous discharge current

瞬间放电电流

100A

200A

400A

400A

Instantaneous  discharge current

显示屏

LCD显示屏/触摸显示屏

LCD display screen/touch screen display

Display

标准充电电流

<25A

<50A

<100A

<100A

Standard charging current

标准放电电流

50A

100A

200A

200A

Standard    discharge current

充电适合温度

0℃~45℃

Charge suitable temperature

放电适合温度

-20℃~65℃

Discharge suitable temperature

电池组尺寸

440*350*155mm

455*480*160mm

580*440*240mm

580*440*240mm

Battery pack size

包装尺寸

455*460*350mm

570*560*365mm

680*520*420mm

680*520*420mm

Package size

电池组净重

25Kg

44Kg

79Kg

82Kg

Net weight of battery pack

电池组毛重

27Kç

46Kg

90Kg

92Kg

Gross weight of battery pack

通讯接口

CAN/RS232/RS485

Communication  interface

冷却方式

自然冷却

Natural cooling

Cooling method

运输分类

UN38.3/MSDS/海运/空运

UN38.3/MSDS/Sea/Air

Transport classification

电池保护功能

过流、过压、过充、过放、短路等

Overcurrent, overvoltage, overcharging, over   discharge, short  circuit, etc!

Battery protection function
